Phóng to Hình sản phẩm

THÔNG SỐ KỸ THUẬT

Model Version	GS1024 4.0
Interfaces	Gigabit RJ45 Ports	24
	Shielded RJ45 Port	Có
	Extend Mode Ports	#1~#22
	VLAN Mode Ports	#1~#22
	LED	Power Speed/Link/Act of Each Ethernet Port
	Physical Buttons	VLAN/Default/Extend DIP Switch
Performance	Max Copper Speed and Distance	Cat. 3 or higher cable: 100 meters at 10 Mbps Cat. 5 or higher cable: 100 meters at 100 Mbps Cat. 5e or higher cable: 100 meters at Gigabit Cat. 5e or higher cable: 250 meters at 10 Mbps
	Copper Speed and Distance Note	250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated.
	MAC Address Table	8192
	Max Switching Capacity	48 Gbps
	Max Forwarding Rate	35.712 Mpps
	Jumbo Frame	15 KB
	Packet Buffer	4 Mbit
Power	Power Input Type	AC Inlet
	Basic Power Saving
	Power Methods	AC
	Power Input	90-260V~ 50/60Hz
	Max Power Consumption	11W
	Idle Power Consumption	6.8W
Switching	802.3 Protocols	802.3x Flow Control 802.3i 10BASE-T 802.3u 100BASE-TX 802.3ab 1000BASE-T
	802.1 Protocols	802.1p: LAN Layer 2 QoS/CoS
	L2 Features	IGMP Snooping Loop Prevention Loop Detection DSCP QoS 802.1p QoS
Reliability	Grounding Methods	Three-Prong Plug Grounding Point
	EMS	IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV
	Environment	Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing
Mechanical	Dimension	270×182×44 mm 10.63×7.17×1.73 inches
	Product Weight	1071.0 g (37.78 oz.)
	Casing Material	Metal
	Installation	Desktop Rackmount via Brackets
Package Content	GS1024 Power Cord Installation Guide Mounting Kit
Ordering Information	Retail Package Dimension	367×245×84 mm 14.45×9.65×3.31 inches
	Retail Package Weight	EU: 1716.4 g (60.54 oz.)
	Units per Carton	5
	Carton Net Weight	EU: 8.6 kg (18.96 lbs)
	Carton Gross Weight	EU: 9.3 kg (20.5 lbs)
	Carton Dimension	38×44×26.5 cm 14.96×17.32×10.43 inches

XEM THÊM THÔNG SỐ

Desktop Switch Cudy 24-Port Gigabit Metal 10/100/1000 Mbps GS1024

Name: Desktop Switch Cudy 24-Port Gigabit Metal 10/100/1000 Mbps GS1024
Brand: Cudy
SKU: 56111
Price: 2079000 VND
Availability: InStock
Rating: 5 (5 reviews)

Mã SP: 0 0 đánh giá Lượt xem: 15 So sánh

Switch để bàn, treo tường :24 Cổng Gigabit. Thông số kỹ thuật: vỏ thép, để bàn, có giá đi kèm. Tính năng: Cắm và chạy, IGMP Snooping, Phát hiện/Ngăn chặn vòng lặp, 802.1p/DSCP QoS, Công tắc DIP chế độ làm việc Chuyển mạch/VLAN/Mở rộng.
