Performance
|
|
| NAT Session | 60K |
| Max. NAT (Mbps) | 700 |
| Max. NAT with Hardware Acceleration : Single WAN (Mbps) | 940 |
| Max. NAT with Hardware Acceleration : Dual WAN (Mbps) | 1800 |
|
WAN
|
|
| Ethernet (1 GbE) | 1 |
|
Ethernet - LAN/WAN Switchable
|
|
| SFP (1G) | 1 |
| Cellular (via USB) | |
| Wireless WAN (2.4GHz + 5GHz) | |
|
Internet Connection
|
|
| IPv4 |
PPPoE
|
|
DHCP
|
|
|
Static IP
|
|
|
PPTP/L2TP
|
|
| IPv6 |
PPP
|
|
DHCPv6
|
|
|
Static IPv6
|
|
|
TSPC
|
|
|
AICCU
|
|
|
6rd
|
|
|
6in4 Static Tunnel
|
|
| 802.1p/q Multi-VLAN Tagging | ✓ |
| Multi-VLAN/PVC | ✓ |
| Failover | ✓ |
| Load Balancing | IP-based, Session-based |
| WAN Active on Demand | Link Failure, Traffic Threshold |
| Connection Detection | ARP, Strict ARP, Ping |
| WAN Data Budget | ✓ |
| Dynamic DNS | ✓ |
| DrayDDNS | ✓ |
|
LAN
|
|
| Fixed LAN (RJ-45, GbE) | 5 |
| LAN Subnet | 8 |
| DMZ Port | 1 |
| VLAN |
802.1q Tag-based VLAN
|
|
Port-based VLAN
|
|
| Max. Number of VLAN | 16 |
| DHCP Server |
Multiple IP Subnet
|
|
Custom DHCP Options
|
|
|
Bind-IP-to-MAC
|
|
| LAN IP Alias | ✓ |
| Wired 802.1x Authentication | ✓ |
| Port Mirroring | ✓ |
| Local DNS Server | ✓ |
| Conditional DNS Forwarding | ✓ |
| Hotspot Web Portal (Profile No.) | 4 |
| Hotspot Authentication |
Click-Through
|
|
Social Login
|
|
|
SMS PIN
|
|
|
Voucher PIN
|
|
|
RADIUS
|
|
|
External Portal Server
|
|
|
Other Ports
|
|
| USB | 2 |
| USB Type | 2.0 |
| FXS (RJ-11) | |
|
Networking
|
|
| Routing |
IPv4 Static Route
|
|
IPv6 Static Route
|
|
|
Policy Route
|
|
|
Inter-VLAN Route
|
|
|
RIP v1/v2
|
|
|
BGP
|
|
| Policy-based Routing |
Protocol
|
|
IP Address
|
|
|
Port
|
|
|
Domain
|
|
|
Country
|
|
| High Availability | ✓ |
| DNS Security (DNSSEC) | ✓ |
| IGMP |
IGMP v2/v3
|
|
IGMP Proxy
|
|
|
IGMP Snooping & Fast Leave
|
|
| Local RADIUS server | ✓ |
| SMB File Sharing (Requires external storage) | ✓ |
|
VPN
|
|
| LAN-to-LAN | ✓ |
| Teleworker-to-LAN | ✓ |
| Protocols |
PPTP
|
|
L2TP
|
|
|
IPsec
|
|
|
L2TP over IPsec
|
|
|
SSL
|
|
|
GRE
|
|
|
IKEv2
|
|
|
IKEv2-EAP
|
|
|
IPsec-XAuth
|
|
|
OpenVPN
|
|
|
WireGuard
|
|
| Max. VPN Tunnels | 50 |
| Max. OpenVPN + SSL VPN Tunnels | 25 |
| IPsec VPN Throughput (AES 256 bits) (single-directional) (Mbps) | 250 |
| IPsec VPN Throughput (Hardware NAT Enabled) | 800 |
| SSL VPN Throughput (single-directional) (Mbps) | 120 |
| WireGuard VPN Throughput (single-directional) (Mbps) | 80 |
| User Authentication |
Local
|
|
RADIUS
|
|
|
LDAP
|
|
|
TACACS+
|
|
|
mOTP
|
|
| IKE Authentication | Pre-Shared Key, X.509 |
| IPsec Authentication | SHA-1, SHA-256 |
| Encryption |
MPPE
|
|
DES
|
|
|
3DES
|
|
|
AES
|
|
| VPN Trunk (Redundancy) | Load Balancing, Failover |
| Single-Armed VPN | ✓ |
| NAT-Traversal (NAT-T) | ✓ |
| VPN Matcher | ✓ |
|
Firewall & Content Filtering
|
|
| NAT |
Port Redirection
|
|
Open Ports
|
|
|
Port Triggering
|
|
|
Port Knocking
|
|
|
DMZ Host
|
|
|
UPnP
|
|
| ALG (Application Layer Gateway) | SIP, RTSP, FTP, H.323 |
| VPN Pass-Through | PPTP, L2TP, IPsec |
| IP-based Firewall Policy | ✓ |
| Content Filtering |
APP
|
|
URL Keyword
|
|
|
DNS Keyword
|
|
|
Web Features
|
|
|
Web Category*(*subscription required)
|
|
| DoS Attack Defense | ✓ |
| Spoofing Defense | ✓ |
|
Bandwidth Management
|
|
| IP-based Bandwidth Limit | ✓ |
| IP-based Session Limit | ✓ |
| QoS (Quality of Service) |
TOS
|
|
DSCP
|
|
|
802.1p
|
|
|
IP Address
|
|
|
Port
|
|
|
Application
|
|
| VoIP Prioritization | ✓ |
| APP QoS | ✓ |
|
Management
|
|
| Local Service |
HTTP
|
|
HTTPS
|
|
|
Telnet
|
|
|
SSH v2
|
|
|
FTP
|
|
|
TR-069
|
|
| Config Backup/Restore | ✓ |
| Config File Compatibility | Vigor2926 |
| Firmware Upgrade | WUI, TFTP, TR-069 |
| 2-Level Administration Privilege | ✓ |
| Access Control | Access List, Brute Force Protection |
| Notification Alert | SMS, E-mail |
| Netflow | v5, v9, IPFIX |
| SNMP | v1, v2c, v3 |
| Syslog | ✓ |
| VPN Managment | 8 |
| AP Managment | 20 |
| Mesh (Number of manageable APs) | |
| Switch Management | 10 |
| VigorACS Management (Since f/w) | V4.2.0.1 |
|
Physical
|
|
| Power Input | DC 12V @ 2A |
| Max. Power Consumption (watts) | 21.6 |
| Dimension (mm) | 241 x 165 x 44 |
| Operating Temperature | 0 to 45°C |
| Storage Temperature | -25 to 70°C |
| Operating Humidity (non-condensing) | 10 to 90% |
