THÔNG SỐ KỸ THUẬT

Model Version	FS1016 1.0
Interfaces	10/100 Mbps RJ45 Ports	16
	Shielded RJ45 Port	Có
	Extend Mode Ports	#1~#14
	VLAN Mode Ports	#1~#14
	LED	Power Link/ACT of Each Ethernet Port
	Physical Buttons	VLAN/Default/Extend DIP Switch
Performance	Max Copper Speed and Distance	Cat. 3 or higher cable: 100 meters at 10 Mbps Cat. 5 or higher cable: 100 meters at 100 Mbps Cat. 5e or higher cable: 250 meters at 10 Mbps
	Copper Speed and Distance Note	250-meter transmission is only available on the Extend Mode ports when the Extend Mode is activated.
	MAC Address Table	8192
	Max Switching Capacity	3.2 Gbps
	Max Forwarding Rate	2.38 Mpps
	Jumbo Frame	2 KB
	Packet Buffer	2 Mbit
Power	Power Input Type	AC Inlet
	Basic Power Saving	Có
	Power Methods	AC
	Power Input	90-260V~ 50/60Hz
	Max Power Consumption	2.0W
	Idle Power Consumption	0.8W
Switching	802.3 Protocols	802.3i 10BASE-T 802.3u 100BASE-TX 802.3x Flow Control
Reliability	Grounding Methods	Three-Prong Plug Grounding Point
	EMS	IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV IEC/EN 61000-4-5, Level 4 Surge: Power: DM 2kV, CM 4kV; RJ45: CM 4kV
	Environment	Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing
Mechanical	Dimension	200×118×44 mm 7.87×4.65×1.73 inches
	Product Weight	600 g (21.16 oz.)
	Casing Material	Metal
	Installation	Desktop Rackmount via Brackets
Package Content	FS1016 Power Cord Installation Guide Mounting Kit
Ordering Information	Retail Package Dimension	230×202×78 mm 9.06×7.95×3.07 inches
	Retail Package Weight	EU: 1050 g (37.04 oz.)
	Units per Carton	10
	Carton Net Weight	EU: 10.5 kg (23.15 lbs)
	Carton Gross Weight	EU: 11.6 kg (25.57 lbs)
	Carton Dimension	48.2×41×22.1 cm 18.98×16.14×8.7 inches

XEM THÊM THÔNG SỐ

Switch Cudy 16-Port 10/100 Mbps Metal FS1016

Name: Switch Cudy 16-Port 10/100 Mbps Metal FS1016
Brand: Cudy
SKU: 56106
Price: 989000 VND
Availability: InStock
Rating: 5 (5 reviews)
