THÔNG SỐ KỸ THUẬT

Form Factor	4U
Dimensions	438.5mm(17.2")W x175mm(6.88")H x800mm(31.4")D
Processor	Dual AMD EPYC™ 9005 series processors, up to TDP 500W
Socket	(2) LGA6096 (Socket SP5)
Memory	(24) DDR5 DIMM Slots, 12 channels(1DPC), RDIMM/RIMM-3DS - Max. Frequency 6400MT/s - Max. Capacity per DIMM: 256GB
Drive Bays	(8) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays (through PCIe switch)
Internal Storage	(2) 2280/22110 PCIe 3.0 x2 NVMe M.2 ports
Expansion Slots	(8) PCIe 5.0 x16 FHFL double wide slots (through PCIe switch) *The system supports 8 x RTX PRO™ 6000 Blackwell Server Edition GPUs at 30°C ambient. (4) PCIe 5.0 x16 FHFL single wide slots (through PCIe switch) (1) PCIe 5.0 x16 FHFL single wide slot (from CPU0)
Networking	(2) 10GBase-T Ethernet Ports with Intel® X710-AT2 (NCSI supported)
Front I/O	(8) Hot-swap 2.5" U.2 drive bays
Rear I/O	(1) 1000Base-T Dedicated Server Management Port (2) 10GBase-T Ethernet ports (1) USB 3.0/2.0 Type-A Port (1) Mini Display port (1) Power LED Button (1) UID LED Button
Security	Chassis Intrusion On-board TPM2.0 Hardware Root of Trust - Microchip CEC1736 supported (optional)
Server Management	(1) 1000Base-T Dedicated Server Management Port ASPEED AST2600 with AMI MegaRAC based firmware supporting IPMI 2.0 and DMTF Redfish API Dual BIOS* and dual BMC eMMC for local BMC storage media * Dual BIOS is exclusively implemented to support the Embedded Root of Trust (ERoT).
OS support	Windows 2025 Ubuntu 24.04 Red Hat 9.5
Environment	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Operating humidity: 8% to 85% (non-condensing) Non-operating Temperature: -30°C ~ 60°C (-40°F to 140°F) Non-operating Relative Humidity: 8% to 90% (non-condensing)
Power Supply	(3+1) Redundant 3200W CRPS 80PLUS Titanium Dimension (WxHxL): 73.5 x 40 x 185 mm Rating: AC Input: 100-120Vac, 16A, 50-60Hz Output: Max 1200W, DC +12V/106.6A, +12Vsb/3A AC Input: 200-219Vac, 16A, 50-60Hz Output: Max 3000W, DC +12V/246A, +12Vsb/3A AC Input: 220-240Vac, 16A, 50-60Hz Output: Max 3200W, DC +12V/262.3A, +12Vsb/3A DC Input: 240V, 16A Output: Max 3200W *C19 power cords are required and will be offered as optional accessories.
Cooling	(2) EVAC air cooling modules for max. 500W CPU (10) 8080 Hot-swap System Fans
Certification	CE, FCC (Class A)
Package Contents	(1) Barebone (1) Quick guide (1) Slide rail Kit (2) CPU Coolers (4) CRPS PSUs (4) Chassis handle (8)Power cables PCIe CEM5(12VHPWR) 16-pin power cables(inside system) (1)Power cable for BlueField-3 DPU
Optional parts	NVL Bridge Removal Tool Power cords: - C19 1.8m 125V/15A(US, NEMA 5-15P): K33-3001279-I45 - C19 1.8m 250V/15A(US, NEMA 6-15P): K33-3001366-I45 - C19 1.8m 250V/16A(EU): K33-3001283-I45 - C19 1.8m 250V/16A(CN): K33-3001280-I45 - C19 1.8m 250V/15A(JP): K33-3001347-I45 - C19 to C20 1.8m 250V/20A(US): K33-3001422-I45 - C19 to C20 1.8m 250V/16A(EU): K33-3001423-I45

XEM THÊM THÔNG SỐ

Máy chủ GPU MSI S6053G480RAU8 | CG480-S6053 (2 CPU AMD EPYC 9005 | 8 GPU | 24 khe DDR5 RDIMM)

Mã SP: 0 đánh giá Lượt xem: 34 So sánh

CPU: Dual AMD EPYC 9005 Series, TDP lên đến 500W. VGA: Hỗ trợ tối đa 8 GPU NVIDIA H200 NVL hoặc RTX PRO 6000 Blackwell Server Edition dạng PCIe. RAM: 24 khe DDR5 RDIMM, 12 kênh trên mỗi CPU (1DPC), tốc độ lên đến 6400 MT/s. Lưu trữ: 8 khay hot-swap U.2 2.5" PCIe 5.0 x4 NVMe phía trước; 2 khe M.2 2280/22110 PCIe 3.0 x2 NVMe.
