Features
Home Cloud - Remote Desktop Anytime, Anywhere
This motherboard supports remote wake with the onboard Intel
® LAN, so you can connect with your PC from anywhere in the world. You will be able to wake up your PC or turn it off, monitor and take control of it remotely with another smartphone, tablet or computer.
Imagine yourself as a desperado riding into the sunset, an outcast of the society exiled from your country, or simply at the groceries two blocks away from home. You miss your personal computer so much and you'll need Home Cloud for the following real world scenarios:
Mail
Keep your stored mail near at hand whenever you need it.
Multimedia
Stream your secret stash of vids, music and pics.
TV
Watch your favorite local TV programs by connecting to your PC.
Documents
Access or send files remotely anywhere.
Monitor
Keep an eye on your pets or children when you are away from home.
Note: Intel
® Remote Wake is supported on Win8 or Win8 64bit OS.
Purity Sound™ - Bask in the Music
Purity Sound is a combination of several hardware, software audio solutions and technologies that will satisfy even the pickiest audiophiles. Including 7.1 CH HD audio with Realtek ALC1150 audio codec, 115dB SNR DAC with Differential Amplifier, TI
® 5532 Premium Headset Amplifier which supports up to 600 ohm headphones, cap less Direct Drive technology, EMI shielding cover, PCB isolate shielding and support for DTS Connect.
Purity Sound™ brings you:
♦ 115dB SNR
♦ Excellent Bass
♦ Less Sound Distortion
♦ More Details
♦ Supports up to 600ohm headphones
Traditional Audio Solution:
♦ 110dB SNR
♦ Poor Bass
♦ More Sound Distortion
♦ Less Details
♦ Does not support high impedance headphones
This frequency response chart was tested with 32 ohm normal headphones. It indicates how traditional audio solution’s frequency response drops drastically at low frequencies. Compared to traditional audio solution’s (2.0dB) at 20 Hz bass low freq area, Purity Sound™ still maintains its frequency response (0.4dB) and provides better bass with the TI
® NE5532 amplifier, improving the bass quality by 20% (1.6dB)!
HDMI-In - The Smart Way to Connect Your Devices
Tired of constantly switching devices to connect to your one and only monitor? From now on just connect the monitor to your motherboard, and connect your secondary device (such as a PS3 or Xbox) to the motherboard’s HDMI-In port. With HDMI-In users may conveniently toggle between the computer’s screen and the secondary device’s screen with a hotkey, or even use their secondary device without powering on the computer.
High Density Glass Fabric PCB
What you’ve never understood about your computer is that it is scared to death of water, H2O, humidity or whatever you’d like to name it. And even though you do not see the water, actually there may be lots of excessive moist in the air killing your motherboard silently and slowly. No, your motherboard doesn’t melt when in contact with water like the wicked witch of the west, but it dies of short circuit. Luckily, ASRock has a new High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.
Premium Gold Caps
This motherboard uses Premium Gold Caps that are 100% made in Japan. These solid capacitors are sleek, high gloss caps with a premium gold coating that represents its long lasting durability and ultra stable performance.
Digi Power
More Precise, More Efficient
Unlike traditional motherboards that use analog power, this motherboard uses a next generation digital PWM (Pulse-Width Modulation) design, which provides CPU Vcore voltage more efficiently and smoothly, so that the stability and lifespan of the motherboard is greatly enhanced.
12 Power Phase Design
Designed with a 12 Power Phase design, this motherboard features sturdy components and completely smooth power delivery to the CPU. Hence, this motherboard offers unmatched overclocking capabilities with the best system stability, plus enhanced performance with the lowest temperature for advanced gamers and extreme overclockers.
Dual-Stack MOSFET (DSM)
Dual-Stack MOSFET (DSM) is an innovative new design of MOSFETs. The silicon die area is increased by stacking two dies into a MOSFET. The larger the die area, the lower Rds(on). Compared to traditional discrete MOSFET, DSM can provide larger die area and lower Rds(on), so the power supply for CPU Vcore is more efficient.
Intel® Dual Gigabit LAN
Users are able to connect two LAN cables to this motherboard's rear i/o. Dual LAN with Teaming function enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective.
4K/2K
4K is a new standard for display resolutions with a minimum of 3840 x 2160 pixels, which is twice the horizontal and vertical resolution of the 1080p format and four times as many pixels overall. Get ready to lose yourself in this eye popping virtual reality.
ASRock APP Shop
ASRock APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can easily optimize your system and keep your motherboard up to date with ASRock APP Shop.
ASRock APP Shop is the only all-in-one software package that delivers you the most practical PC apps and tools, in one integrated interface – from ASRock exclusive tools to the most update-to-date options of the latest technology.
Orbweb ME :
Get Connected with ASRock Cloud Anytime, Anywhere
App Charger :
Fast Charge & Charge Anytime
Google Chrome :
Better Browsing with Google Options
XFast LAN :
Your Smartest Internet Access Manager
A-Tuning
A-Tuning is ASRock's multi purpose software suite with a new interface, more new features and improved utilities, including EZ OC, Auto Tuning, XFast 555, OC Tweaker, System Browser, Live Update, Tech Service and a whole lot more!
Triple Monitor
Graphics, graphics and even more graphics! You've demanded for more eye candy, so this motherboard supports Triple Monitor. You may choose up to three display interfaces from the rear i/o to connect monitors and use them simultaneously without installing another graphics card.
Distortion-Free Slot
ASRock strives for perfection and cares about even the most unnoticeable details when it comes to making motherboards better! This exclusive new pin design for the motherboard's memory slots called Distortion-Free Slots effectively reduce distortion and improve performance.
Traditional pin design
New Distortion-Free Slot
* Shorter pin design
* Reduces signal distortion
Tired of listening to crappy audio that makes your ears bleed? Experience high-quality surround sound from your personal computer. DTS Connect is a blanket name for a two-part system, including DTS Interactive and DTS Neo:PC, it is used on the computer platform only, in order to convert PC audio into the DTS format.
Front USB 3.0 Panel
This motherboard comes with a free front USB 3.0 panel that not only provides two high speed USB 3.0 ports for connecting your peripherals, but it also serves as a 2.5” hard disk drive or solid state drive rack.
Fully Optimize Memory Usage
Faster Internet Access
Boosts up your USB speed
5X Faster for
Photoshop Execution
XFast RAM will create a virtual disk from the system memory to boost the performance. For Photoshop, It can even perform 5X faster than before.
Lower Latency
In Game
XFast LAN can lower latency in the game after setting online game priority higher.
Time latency in World of Warcraft: Cataclysm
* Lower is better
USB Performance
Comparison
ATTO Disk Benchmark 4K Read
ASRock Motherboard
Other Motherboard
*The performance boost percentage may vary with a different configuration.
FAN-Tastic Tuning
Configure different fan speeds for respective temperatures using the graph. The fans will automatically shift to the next speed level when the assigned temperature is met.
Easy Driver Installer
For users that don’t have an optical disk drive to install the drivers from our support CD, Easy Driver Installer is a handy tool in the UEFI that installs the LAN driver to your system via an USB storage device, then downloads and installs the other required drivers automatically through the internet. Completely no CD or optical disk drive required!
USB Key
In a world where time is money, why waste precious time everyday typing usernames to log in to Windows? Why should we even bother memorizing those foot long passwords? Nobody has time for that! Just plug in the USB Key and let your computer log in to windows automatically!
UEFI Tech Service
Contact ASRock Tech Service by sending a support request from the UEFI setup utility if you are having trouble with your personal computer. Users may try to choose the category of the issue they have encountered, describe the problem in detail, and then attach an optional picture or log file for our technical support team.
Fast Boot
With ASRock’s exclusive Fast Boot technology, it takes less than 1.5 seconds* to logon to Windows
® 8 from a cold boot. No more waiting! The speedy boot will completely change your user experience and behavior.
*The boot time may vary with a different configuration.
UEFI System Browser
UEFI system browser is a useful tool included in ASRock's graphical UEFI. It can detect the devices and configurations that users are currently using on their motherboard. With UEFI system browser, you can easily examine the current system configuration in the UEFI setup without having to open the chassis and take everything apart.
Restart to UEFI
Fast Boot is so fast that it is impossible for users to enter the UEFI setup utility during POST. Therefore, ASRock Restart to UEFI technology allows users to easily enter the UEFI setup utility automatically when turning on the PC next time. It is designed for those who constantly need to enter the UEFI setup utility.
Dehumidifier
Dampness kills most electronics, so it's a better idea to keep your personal computer dry. Now users may prevent motherboard damages due to dampness by enabling Dehumidifier. When it is enabled, the computer will power on automatically to dehumidify the system after entering S4/S5 state.
OMG
Limit and control your children's time spent on the internet. ASRock OMG (Online Management Guard) technology allows you to establish an internet curfew or restrict internet access at specified times. Administrators are able to schedule the starting and ending hours of internet access granted to other users.
This motherboard supports HDMI™ (High-Definition Multimedia Interface) which is an interface standard for transferring uncompressed video data and delivering multi-channel audio through a single cable. Both video and audio data signals transferred through the HDMI™ interface are digital without being converted into analog, therefore it delivers the richest pictures and the most realistic sounds.
